l The bedstead is made of aluminium alloy.
l The accessories、base shell and column shell all are made of stainless steel.
l The main accessory hydraulic pump and electromagnetic valve are adopted imported component
l The tabletop is made of Paper plywood(double-layer),there is a film-frame in the interlayer,it is convenient to Move the radiography Position.
l The leg board can be forked and abducted 180o,folded down 90o.It is suitable for urinary、obstetrics and Gynecology surgery
Main specification parameters
|
Item |
Contents |
|
Length and width of table |
2050mmx480mm |
|
Max.&Min.Height of table |
950mmx700mm |
|
Max.degree of forward and backward tilting of table |
forward≥20o backward≥20o |
|
Max.degree of left and right tilting of table |
left≥18o right≥18o |
|
Range of back rest adjustment |
up≥75o diwb≥20o |
|
Max.degree of leg rest adjustment |
≥90o abduction 180o |
|
Range of head rest adjustment |
up≥75o down≥90o detachable |
|
Waist board |
≥120mm |
|
Power |
~200V 50Hz 1.0Kw | |
